Face Gear Clutch

Precision Custom Face Gear Clutch - 5-Axis CNC Machining

Ganyuan Factory has focused on manufacturing face gear clutches for over 20 years. Relying on high-precision CNC equipment and professional heat treatment processes, we strictly control the accuracy of the face gear profile, the hardness of the meshing surface, and the axial fit tolerances to ensure precise engagement, rapid response, and long-term durability in power transmission and disengagement.



Product description

Production Type Customized production and processing Material stainless steel
Workmanship CNC lathe machining, five axis CNC machining, polishing Applied to Mechanical components, etc
Size

D180*90



 Proofing time

7-15
Precision

±0.02mm

 Do you want to make a sample Yes

OEM/ODM

OEM ODM CNC machining services

 Place of Origin Dongguan, China
type Manufacturers/factories and trading companies Main products Numerical control part; Processing parts; stainless steel parts
Management system certification

ISO 9001:2015

 Production capacity

 100000

CNC Precision Face Gear Clutch Machining Experts

As a core clutch and torque transmission component in mechanical transmission systems, the machining accuracy and meshing performance of the face gear clutch directly affect the smoothness of power engagement, torque transmission efficiency, and service life of the equipment. We specialize in the research and development and manufacturing of various face gear clutches. Relying on advanced multi-axis CNC equipment and professional gear machining processes, we provide high-precision, high-torque, and high-reliability clutch solutions for automotive transmissions, construction machinery, industrial transmissions, aerospace, and other fields.

Professional CNC Face Gear Clutch Machining Technology

We are equipped with five-axis CNC machining centers, high-precision CNC gear shapers, and dedicated forming grinders. Using a dedicated gear machining tool system, we can machine various precision face gear clutches with outer diameters of φ50-φ500mm, 6-120 teeth, modules of 1-8, and precision levels reaching ISO 6 or higher. Through optimized multi-process collaborative machining strategies and online measurement technology, the tooth profile error is ensured to be no more than 0.008mm, the tooth direction error controlled within 0.006mm, the tooth surface roughness to Ra0.8μm, and the end face runout of the gear ring controlled within 0.01mm.

High-Quality Materials and Heat Treatment Processes

High-quality alloy steels such as 20CrMnTi, 40Cr, 42CrMo, GCr15, and 65Mn, along with spring steel, are selected, combined with advanced heat treatment processes such as carburizing and quenching, high-frequency quenching, and tempering. By precisely controlling heat treatment parameters, a tooth surface hardness of HRC58-62, a hardened layer depth of 0.8-1.5mm, and a core toughness of HRC30-40 are achieved. For different operating conditions: 20CrMnTi deep carburizing is used for automotive transmission clutches; 40Cr combined with high-frequency quenching is used for engineering machinery; 42CrMo alloy steel is used for high-torque applications; and GCr15 bearing steel is used for high-speed clutches.

Advanced Processes Overcome the Challenges of Face Gear Machining

The manufacturing of face gear clutches faces technical challenges such as controlling the precision of the face gear profile, ensuring tooth direction consistency, and correcting deformation during heat treatment. We have effectively solved these challenges through innovative processes: employing CNC forming grinding and online compensation technology to control tooth profile errors within 0.005mm; utilizing high-precision indexing and grinding processes to ensure tooth direction consistency; and employing PVD coating technology to increase the tooth surface hardness to over HV2000.



Our CNC precision face gear clutches are widely used in important fields such as automotive synchronizers, engineering machinery shifting mechanisms, aerospace transmission systems, agricultural machinery power output, and machine tool transmission mechanisms. With professional face gear machining technology and extensive experience in heat treatment, we are committed to providing every customer with the highest quality face gear clutch products, using precision manufacturing technology to provide reliable clutch and torque transmission guarantees for mechanical transmission systems.
