Stainless Steel Pinion Gears

Precision CNC Machining of 5-Axis Stainless Steel Pinion Gear Components

We specialize in the five-axis precision machining of stainless steel pinion gears, equipped with high-end five-axis CNC machine tools and professional testing systems. From micro-tooth profile design to mass production, we provide end-to-end manufacturing services, ensuring that each gear possesses precise meshing performance, excellent wear resistance, and long-term corrosion resistance, meeting the stringent requirements of high reliability and durability for miniature transmission systems.



Product description

Production Type Customized production and processing Material stainless steel
Workmanship CNC lathe machining, five axis CNC machining, polishing Applied to Mechanical components, etc
Size

D180*90



 Proofing time

7-15
Precision

±0.02mm

 Do you want to make a sample Yes

OEM/ODM

OEM ODM CNC machining services

 Place of Origin Dongguan, China
type Manufacturers/factories and trading companies Main products Numerical control part; Processing parts; stainless steel parts
Management system certification

ISO 9001:2015

 Production capacity

 100000

Precision Manufacturing Technology and Core Advantages of Stainless Steel Pinions

As a core component of precision transmission systems, the manufacturing precision of stainless steel pinions directly determines the motion accuracy, torque transmission efficiency, and service life of the equipment. In key fields such as precision instruments, stainless steel pinions, with their excellent corrosion resistance, superior structural strength, and sanitary surface properties, have become indispensable core transmission components under harsh working conditions.

Core Technical Characteristics of CNC Machining of Stainless Steel Pinions

1. High-Precision Tooth Profile Composite Forming Technology

Modern stainless steel pinions, based on meshing principles and dynamic simulation optimization, employ involute, cycloidal, or composite tooth profile designs to achieve smooth meshing and precise transmission within a limited space. Five-axis CNC machining centers, through a combination of precision hobbing and milling processes, accurately transform the complex tooth profiles in the digital model into solid tooth shapes, controlling the tooth profile shape error within JIS Class 0 precision, adjacent pitch error less than 0.002mm, and tooth surface roughness below Ra0.4, ensuring precise fit and low-noise operation of micro-module gears.

2. Dedicated Machining System for Stainless Steel Materials

Targeting the material properties of different grades of stainless steel such as 304, 316L, 17-4PH, and 440C, the CNC system automatically matches the optimal cutting parameters through a dedicated stainless steel process database. High-performance coated tools and high-pressure cooling technology are employed to effectively control work hardening, achieving an ideal tooth surface free of burrs and burns during precision gear hobbing.

3. Dimensional Consistency Control Technology for Microstructures

Stainless steel pinions are often designed with miniature shaft diameters, thin-walled structures, and precision internal holes, requiring extremely high machining accuracy. CNC machining utilizes high-precision spring collets and online measurement compensation technology to complete the precision machining of tooth profiles, shaft diameters, and internal holes in a single setup. Shaft diameter tolerances are controlled within IT5 accuracy level, and internal hole roundness is less than 0.002mm, ensuring precise fit between the pinion and bearings/shafts.



The CNC precision manufacturing of stainless steel pinions, through achieving precise forming of high-precision tooth profiles, optimization of stainless steel material processing depth, and guarantee of dimensional consistency of microstructures, successfully transforms advanced transmission design concepts into highly reliable transmission components. This technology not only embodies the modern pursuit of both corrosion resistance and high precision in precision transmission, but also provides key core component support for long-term reliable operation in harsh environments, driving small module gear technology to continuously advance towards higher precision, stronger corrosion resistance and longer life.
