Aluminum Spiral Components

High-Precision CNC Machining of Aluminum Spiral Components Metal Structural Parts

Ganyuan Factory has focused on manufacturing aluminum spiral components for over twenty years. Relying on high-precision CNC equipment and professional testing technology, we strictly control the thread lead accuracy, spiral surface finish, and overall wear resistance, ensuring that the spiral components possess lightweight, low inertia, and smooth operation characteristics during transmission.



Product description

Production Type Customized production and processing Material aluminum
Workmanship CNC lathe machining, five axis CNC machining, polishing Applied to Mechanical components, etc
Size

D180*90



 Proofing time

7-15
Precision

±0.02mm

 Do you want to make a sample Yes

OEM/ODM

OEM ODM CNC machining services

 Place of Origin Dongguan, China
type Manufacturers/factories and trading companies Main products Numerical control part; Processing parts; stainless steel parts
Management system certification

ISO 9001:2015

 Production capacity

 100000

Aluminum Spiral Components: Precision Carriers for Lightweight Design and Complex Motion Control

In modern mechanical transmission and fluid control systems, aluminum spiral components, with their unique geometric structure and material advantages, have become key functional components for realizing the conversion between rotary and linear motion, fluid transport, and energy transfer. We focus on providing customers with high-quality aluminum spiral component solutions through five-axis precision machining technology, perfectly integrating lightweight design with complex motion control.

Five-Axis Linkage Machining: Integrated Precision Forming of Complex Helical Surfaces

The core technology of aluminum spiral components lies in their continuous helical surface, precise lead control, and complex end structures. Traditional turning or milling processes struggle to complete the high-precision forming of helical surfaces in a single setup. Our five-axis linkage CNC machining center, through multi-axis collaborative motion and intelligent programming systems, can directly machine integrated spiral components with variable lead helices, multi-start threads, tapered helices, and complex end face structures from a single piece of aluminum alloy material.

Comprehensive Precision Assurance System

We have established a complete technical service system, from helical surface design, material selection, process optimization to comprehensive performance testing. During the design phase, we utilize specialized software for helical parameter optimization and meshing performance analysis to ensure the design meets specific motion or conveying requirements. During production, we are equipped with high-precision coordinate measuring machines, helical line measuring instruments, and optical profilometers to comprehensively test the lead accuracy, helical surface profile, surface quality, and actual working performance of the helical components.

Material Advantages and Lightweight Design

We select high-quality aluminum alloys such as 6061, 7075, and 2024, which possess excellent strength-to-weight ratio, good thermal conductivity, and outstanding machinability. Through optimized heat treatment processes, the materials achieve ideal comprehensive mechanical properties and dimensional stability. In structural design, we employ topology optimization and thin-wall reinforcement technology to achieve maximum lightweighting while ensuring sufficient rigidity.



With five-axis precision machining as our core capability, we integrate helical theory, materials science, and advanced manufacturing technology to provide customers with precise, efficient, lightweight, and reliable aluminum helical component solutions. Choosing us means choosing to equip your motion and fluid control systems with a precise and reliable "helical core," ensuring every rotation and conveying is accurate, efficient, and smooth.

Company Profile

         We are a manufacturer integrating industry and trade. We have more than 20 years of experience in production technology. We are located in Dongguan City, Guangdong Province, China. We have advanced high-end professional production and processing technology, and are committed to innovative R&D and production. After years of market tempering and exploration, it has high-quality technical management personnel, experienced designers, R&D personnel and a perfect company management system.

5-axis CNC workshop

         Our factory has a plant area of about 2,000 square meters and masters core processing technologies. It has high-end precision production equipment: CNC lathes, 5-axis CNC, 4-axis CNC, stamping equipment, die-casting equipment, etc.​

Auxiliary production equipment: electroplating, anodizing, hard anodizing and surface treatment. We have complete testing equipment: sophisticated three-dimensional testing, two-dimensional testing, hardness tester, height meter, projector and other conventional testing equipment. If you are interested in our products, please contact me and I will provide the best price support and quality service.

2D inspection equipment

Product Packaging

Packaging Details

  1. Commercial packaging: 1pc/plastic bag + color box +carton + pallet;
  2. Industrial packaging: (1). plastic tube + carton + pallet; (2). plastic bag + kraft paper + carton + pallet;
  3. According to the requirement of customer.
